Optoma ZU607TST 6000-Lumens WUXGA Short Throw Golf Simulator Projector
By Optoma
More Brightness Headroom, Factory Golf Color.
The ZU607TST steps up from the ZU507TST with 6,000 lumens of laser brightness and a factory Golf Sim Picture Mode tuned for true-to-life greens and blues under real lighting. It keeps the same fixed 0.58:1 short-throw lens, IP6X-sealed 24/7 optical engine, and manual lens shift — making it the pick for bays with more ambient light or larger screens that need the extra output.
Extra Lumens And Golf-Tuned Color, Same Reliable Platform.
6,000-Lumen Laser Output
A brighter laser engine than the ZU507TST gives more headroom for larger screens or bays with skylights, garage doors, and overhead lighting that stays on.
Factory Golf Sim Picture Mode
Optoma's Golf Sim Picture Mode is calibrated specifically for simulator visuals, delivering true-to-life greens and blues with the lights on rather than relying on a generic cinema profile.
Fixed Short-Throw Lens
A 0.58:1 fixed throw ratio keeps the projector close to the screen and out of the swing path, well suited to standard-depth simulator bays.
Manual Lens Shift
Vertical lens shift from -100 to +110 percent and horizontal shift of ±4 percent give real placement flexibility for off-center mounts.
IP6X Dust-Sealed Engine
An independently certified IP6X optical engine is rated for 24/7 operation, suited to bays and facilities running frequent daily sessions.
Louder Built-In Audio
Dual 15W built-in speakers step up from the 10W speakers on the ZU507TST, giving more usable volume without external speakers in smaller rooms.
Who Is It Best For?
Builders who want the ZU507TST's fixed-lens installation-grade platform but need more brightness headroom for a larger screen or a bay with more ambient light, plus factory golf color tuning out of the box.
Fixed Optics, Straightforward Placement.
Fixed Short-Throw Geometry
The ZU607TST uses the same fixed 0.58:1 lens as the ZU507TST, with no zoom to plan around — just one throw ratio to design a mount for.
- 0.58:1 fixed short-throw ratio, no zoom
- Rated for screens from 30″ to 300″ diagonal
- Ideal for standard-depth home and light-commercial simulator bays
- Native 16:10, compatible with 16:9 and 4:3
Lens Shift & Setup Tools
Manual lens shift and keystone correction handle mounts that cannot sit dead-center on the screen.
- Manual lens shift — vertical -100/+110%, horizontal ±4%
- Auto vertical keystone plus ±15° horizontal/vertical manual correction
- Four-corner correction for squaring the image in real-world rooms
- Use the ESG fitment tool to confirm exact mounting distance before installing
A Brighter Fixed-Lens Laser With Golf-Tuned Color.
The ZU607TST is a WUXGA fixed short-throw laser projector rated for approximately 30,000 hours of light source life, built around the same IP6X dust-resistant, 24/7-rated optical engine as the ZU507TST but with 6,000 lumens of output and a factory Golf Sim Picture Mode tuned specifically for simulator color grading.
Optoma publishes a projection distance range of 0.38 to 3.75 meters (about 15″ to 148″) and a screen size range of 30″ to 300″ diagonal for the fixed 0.58:1 lens. Because the exact mounting distance depends on screen width and aspect ratio, run the numbers in the projector fitment tool and throw calculator before finalizing a mount.
Ceiling mount notes: manual vertical lens shift from -100 to +110 percent and horizontal shift of ±4 percent give installers meaningful slack on placement, and auto vertical keystone plus four-corner correction handle any remaining geometry without excessive digital correction.
For PC-based simulators running GSPro, E6 Connect, TGC 2019, or Awesome Golf, the ZU607TST connects via dual HDMI 2.0 inputs, with HDBaseT and RJ45 available for longer commercial cable runs, and its Golf Sim Picture Mode is calibrated to keep greens and blues accurate under typical bay lighting.
The Full ZU607TST Feature Set.
WUXGA Native Resolution
Native 1920 × 1200 resolution with 1.07 billion displayable colors, plus support for 4K signal input up to 3840 × 2160 at 60Hz.
Fixed Short-Throw Projection
0.58:1 fixed throw ratio fills 30″ to 300″ screens from a consistent, predictable mounting distance with no zoom variable.
6,000-Lumen Brightness
Extra brightness headroom over the ZU507TST for larger screens or bays with more ambient light, without sacrificing laser reliability.
Golf Sim Picture Mode
A factory color mode calibrated specifically for golf simulation, lifting greens and blues for accurate course visuals under typical bay lighting.
HDR10 & HLG Support
Wide dynamic range support adds contrast depth on top of the native WUXGA panel for both simulator visuals and other content.
Installer Connectivity
2× HDMI 2.0, 2× VGA, composite video, HDBaseT, RJ45 network control, RS232, USB-A power, and 2×15W built-in speakers.
ZU607TST Key Specifications.
| Resolution | WUXGA (1920 × 1200), native 16:10 |
|---|---|
| Brightness | 6,000 lumens |
| Contrast Ratio | 300,000:1 |
| Light Source | Laser, up to 30,000-hour life |
| Throw Ratio | 0.58:1 (fixed short throw) |
| Zoom | None (fixed lens) |
| Lens Shift | Vertical -100%/+110%, Horizontal ±4% (manual) |
| Keystone | ±15° horizontal/vertical, auto vertical keystone, four-corner correction |
| Projection Distance | 0.38m – 3.75m (14.96″ – 147.6″) |
| Screen Size Range | 30″ – 300″ diagonal |
| HDR Support | HDR10, HLG |
| 3D Support | Full 3D |
| Connectivity | 2× HDMI 2.0, 2× VGA, composite video, HDBaseT, RJ45, RS232, USB-A power, 2× audio 3.5mm |
| Speakers | 2× 15W built-in |
| Operating Noise | 33 dB (eco) – 36 dB (normal) |
| Power Consumption | 240W (min) – 366W (max), <0.5W standby |
| IP Rating | IP6X dust-resistant optical engine |
| Dimensions (W×D×H) | 374 × 302 × 117 mm (14.72″ × 11.89″ × 4.61″) |
| Weight | 6.3 kg (13.89 lbs) |
| Dealer Status | Elite Sim Golf Authorized Optoma Dealer |
Optoma WUXGA & 4K Short-Throw Projectors.
The ZU607TST sits above the ZU507TST for brightness and adds factory golf color tuning. These comparisons show where it fits against its closest WUXGA sibling and Optoma's compact 4K short-throw option.
- Resolution: WUXGA (1920×1200)
- Brightness: 5,000 lumens
- Light Source: Laser (30,000 hrs)
- Throw Ratio: 0.58:1 (fixed)
- Lens Shift: Vertical -100/+110%, Horizontal ±4%
- Contrast: 300,000:1
- Native Aspect Ratio: 16:10
- IP Rating: IP6X
- Resolution: WUXGA (1920×1200)
- Brightness: 6,000 lumens
- Light Source: Laser (30,000 hrs)
- Throw Ratio: 0.58:1 (fixed)
- Lens Shift: Vertical -100/+110%, Horizontal ±4%
- Contrast: 300,000:1
- Native Aspect Ratio: 16:10
- IP Rating: IP6X
- Resolution: 4K UHD (3840×2160, pixel-shift)
- Brightness: 4,000 lumens
- Light Source: Laser
- Throw Ratio: 0.5:1 (fixed ultra-short throw)
- Lens Shift: None (fixed)
- Contrast: 2,000,000:1
- Native Aspect Ratio: 16:9
- IP Rating: Not rated
Extra Brightness, Golf Color Built In.
Choose the Optoma ZU607TST for a fixed-lens laser projector with 6,000 lumens of brightness, a factory Golf Sim Picture Mode, IP6X sealing rated for 24/7 operation, and manual lens shift for off-center mounting — built for bays that need more headroom than an entry-level laser projector provides.
Pair It With An Elite Sim Golf Enclosure
The ZU607TST's extra brightness holds up well in a properly sized Eagle 12 enclosure with an impact screen matched to its fixed 0.58:1 throw ratio. Confirm exact mounting distance with the fitment tool before finalizing an install.
Build A Complete SimKit
Configure a turnkey enclosure-plus-projector package or build a custom bay around the ZU607TST from the ground up using the SimKit Bundle Builder.
